Fan Motor Options
14.1.1 Constant Torque Motor Performance Data—Vertical Configuration
Model Tap #
Default Factory
Motor Setting
CFM
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20
RF007
1 FO 213 192 171 154 — — — — — — — —
2 DH 306 290 275 260 246 233 217 — — — — —
3 FL 345 331 318 304 292 279 267 — — — — —
4 439 425 412 400 390 380 371 — — — — —
RF009
1 FO 232 215 198 183 168 — — — — — — —
2 DH 328 317 305 293 280 268 258 — — — — —
3 FL 368 355 344 334 321 311 301 — — — — —
4 451 442 434 424 416 406 378 — — — — —
RF012
1 FO 278 260 242 225 205 — — — — — — —
2 DH 402 392 379 365 353 341 328 315 — — — —
3 FL 436 430 418 406 394 383 372 362 — — — —
4 541 526 523 502 481 459 437 413 — — — —
Note: DH = Dehumidification, FL = Full Load, and FO = Fan Only
Table 12 Constant Torque Motor Performance Data—Vertical Configuration
Off delay = 30 seconds = After receiving an OFF command
motor will continue running for 30 seconds. CFM based on
wet coil and 1" Merv 5 Throwaway. DH is the default tap for
Dehumidification.
38 |
RF Series Heat Pumps — 8733980022 (2024/12)
