24 | RG8.0 / RG4.0 | Symbols useden
1. Symbols used
1.1 In the documentation
1.1.1 Warning notices -
Structure and meaning
Warning notices warn of dangers to the user or people
in the vicinity. Warning notices also indicate the con-
sequences of the hazard as well as preventive action.
Warning notices have the following structure:
Warning
symbol
KEY WORD – Nature and source of hazard!
Consequences of hazard in the event of fail-
ure to observe action and information given.
¶ Hazard prevention action and information.
The key word indicates the likelihood of occurrence and
the severity of the hazard in the event of non-observance:
Key word Probability of
occurrence
Severity of danger if in-
structions not observed
DANGER Immediate
impending danger
Death or severe injury
WARNING
Possible impending
danger
Death or severe injury
CAUTION Possible dangerous
situation
Minor injury
1.1.2 Symbols in this documentation
Symbol Designation Explanation
!
Attention Warns about possible property damage.
i
Information Practical hints and other
useful information.
1.
2.
Multi-step
operation
Instruction consisting of several steps.
e
One-step
operation
Instruction consisting of one step.
Intermedi-
ate result
An instruction produces a visible
intermediate result.
"
Final result There is a visible final result on
completion of the instruction.
1.2 On the product
! Observe all warning notices on products and ensure
they remain legible.
Read the original
instructions before operation.
Wear protective goggles.
Wear a safety mask.
Wear protective gloves.
Risk of electric shock
Do not open the panels while operating
the RG8.0 / RG4.0. Touching live parts
may result in electric shock.
Risk of fire
¶ Do not use equipment in the vicinity of
spilled or open containers of gasoline
or other flammable substances.
¶ RG8.0 / RG4.0 is designed to operate in
nor mal or non-hazardous environments.
Do not use this equipment in
hazardous/explosive environments.
