29
Bosch Security Systems 09/06 BLCC100R
Solution 16
plus
Quick Start Guide
Devices > Keypads >
Beeper Options MENU 6-1-5
1 Trouble Alert Beeps Y
2 Entry Warning Y
3 Exit Warning Y
4 Chime Tone Y
5 Display Temperature N
6 PIN Arming Not Allowed N
7 Intaller PIN Not Allowed N
8 Show Alarm When Armed N
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
Devices > Keypads >
Emergency Keys MENU 6-1-6
1 Audible Keypad Fire Y
2 Report Keypad Fire Y
3 Audible Keypad Medical Y
4 Report Keypad Medical Y
5 Audible Keypad Panic (Invisible If Not Set) Y
6 Report Keypad Panic Y
7 Reserved N
8 Reserved N
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
Devices > Keypads >
Access Group
MENU 6-1-7
0
Use Keys [] and [] keys or enter 1 - 8 + [OK] To Assign The Keypad
To An Access Group.
Devices > Keypads >
Lockout Time
MENU 6-1-8
0 6 0
SECONDS
Enter 0 – 255 + [OK] To Program The Keypad Lockout Time In
Seconds. 0 = No Lockout (*** System Wide Parameter ***)
Devices > RF Devices >
Receiver Options MENU 6-2-0
1 Display RF Receiver Trouble Y
2 Alarm On RF Receiver Tamper Y
3 Report RF Receiver Tamper Y
4 Alarm On RF Receiver Jam Detect N
5 Report RF Receiver Jam Detect N
6 Alarm On RF Receiver Comms Fail Y
7 Report RF Receiver Comms Fail Y
8 Reserved N
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
Device > RF Devices >
Supervision Time
MENU 6-2-1
0 2 4
HOURS
Enter the RF Supervision Time for Devices in Hours (001 - 255 Hours)
000 = No Supervision
Device > RF Devices >
RF Device Options MENU 6-2-2
1 Display RF Tamper Y
2 Report RF Tamper Y
3 Report RF Low Battery Y
4 Report Lost RF Device Y
5 Open Zone On Lost RF N
6 Audible Keyfob Panic Y
7 Report Keyfob Panic Y
8 Keyfob Function 1 Key = Part On Y
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
Devices > RF Devices >
Add RF Keypad
MENU 6-2-3
Delete RF Keypad
MENU 6-2-4
View RF Device ID
MENU 6-2-5
Devices > Serial Device >
Device Type
MENU 6-3-0
0 = Disabled
0
1 = Serial Printer
2 = Computer
Use Keys [] and [] keys or enter 0 – 2 + [OK] To Program The Type
Of Serial Device Connected To The Serial Port.
Devices > Serial Device >
Baud Rate
MENU 6-3-1
0 = No Device Connected
0
1 = 300 Baud 5 = 9600 Baud
2 = 600 Baud 6 = 19200 Baud
3 = 1200 Baud
4 = 2400 Baud
Use Keys [] and [] keys or enter Digits 0 – 6 To Program The Serial
Device Baud Rate, Then Press [OK] To Save.
Devices > Serial Device >
Flow Control
MENU 6-3-2
0 = No Handshaking
0
1 = Hardware
2 = Xon-Xoff
Use Keys [] and [] keys or enter Digits 0 – 2 To Program The Serial
Device Flow Control, Then Press [OK] To Save.
