Solution 16
plus
32
Bosch Security Systems 09/06 BLCC100R
Quick Start Guide
System > System Options >
General Options MENU 7-7-0
1 Display LAN Fail Y
2 Report LAN Fail Y
3 Alarm On LAN Fail N
4 Reserved N
5 Can Change Own PIN Code N
6 Monitor Default PIN Codes Y
7 PIN Always Required N
8 Display Menu Numbers Y
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
(*** System Wide Parameter ***)
System > System Options >
Area Options MENU 7-7-1
1 Area 1 = Common Area N
2 First To Open Last To Close N
3 Reset Siren All Users (All Areas) Y
4 Power Up In Same State As Powered Down Y
5 Fault Acknowledge All Areas Y
6 Delay Trouble Beeps Y
7 Power Up Disarmed N
8 Reserved N
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
(*** System Wide Parameter ***)
System > Options >
Keypad Idle Screen
MENU 7-7-2
0 = No Idle Screen 0
1 = Date and Time
2 = Time
3 = Custom Screen
(*** System Wide Parameter ***)
Use Keys [] and [] keys or enter 0 - 3 Then Press [OK] To Program
The Keypad Idle Screen - Single Option Only.
System > Options >
Keypad Hi/Lo Temp
MENU 7-7-3
0 0 ˚C 0 0 ˚C
(*** System Wide Parameter ***)
Hi TEMP Lo TEMP
Use Keys [] and [] keys To Program The High / Low Keypad Monitor
Temperature. Max = 50 Min = 0
System > Installer Options >
Installer Options MENU 7-7-4
1 Report/Log Entry/Exit Intstaller Menu N
2 Report/Log Program Data Change Y
3 Arm Only Installer Pin N
4 Reserved N
5 Auto Exit Installer Menu In 2 Hours Y
6 Auto Exit Service mode In 2 Hours Y
7 Reserved N
8 Factory Defaulting Allowed Y
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
(*** System Wide Parameter ***)
System >Options >
Language
MENU 7-7-5
0 = English 0
1 = Alternate Language
(Enter Digits 0 – 15 To Program Area, Output or Access Group Number,
Then Press [OK] To Save
System > System Testing >
Walk Test All Zones
MENU 7-9-0
Battery Test
MENU 7-9-1
Te sting The Sys tem
You will need to be in programming mode before accessing
the test functions listed below.
Walk Test
Use the walk test command MENU 3-9-0 to test and verify
that all zones work correctly.
External Audible Test
Use MENU 4-9-0 to test and verify that all horn speakers
operate. This test will sound the horn speaker for two
seconds.
Internal Audible Test
Use MENU 4-9-1 to test and verify that all 12 VDC sirens
operate. This test will sound the siren for two seconds.
Strobe Test
Use MENU 4-9-2 To test and verify that the strobe operates.
This test will turn on the strobe until you manually stop the
test.
Battery Test
Use MENU 7-9-1 to test the back-up battery that is
connected to the control panel.
