Bosch Security Systems 09/06 BLCC100R
Solution 16
plus
Quick Start Guide
System > Power >
Battery Options MENU 7-3-1
1 Display Battery Fail Y
2 Report Battery Fail Y
3 Execute Battery Testing On Arming Y
4 Arming Allowed On Low Battery Y
5 Reserved N
6 Reserved N
7 Reserved N
8 Reserved N
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
System > Power >
Fuse Options MENU 7-3-2
1 Display COMM+ Current Overload Condition Y
2 Report COMM+ Current Overload Condition Y
3 Display +12V (Accessories) Current Overload Condition Y
4 Report +12V (Accessories) Current Overload Condition Y
5 Display LAN+ Overload Condition Y
6 Report LAN+ Overload Condition Y
7 Reserved N
8 Reserved N
Use Keys [] and [] to scroll up and down the option list. With option
selected press ON / OFF key to enable or disable option. [] will display
to indicate option set. Press [OK] To Save when finished.
System > Siren >
Tone
MENU 7-4-0
Speed
MENU 7-4-1
Volume
MENU 7-4-2
(*** System Wide Parameter ***)
1 5
Enter 0 – 15 + [OK] To Program Volume Of The Siren Volume
(0 = Disabled / 1 = Low – 15 = High)
System > Siren >
Swinger Siren
MENU 7-4-3
3
Enter 0 – 15 + [OK] To Program Number Of Times Siren Can Sound
Before Lockout. (0 = Unlimited) (*** System Wide Parameter ***)
System > Schedules >
Name
MENU 7-5-0
S c h e d u l e 1 N a m e
Use [] and [] Keys To Scroll Cursor Left and Right. Use Keys [0]
– [9] + [#] and [*] To Toggle Characters + Enter [OK] To Save
System > Schedules >
Time
MENU 7-5-1
Start Time Stop Time
12 : 00 am 12 : 00 am
HH MM HH MM
Use the [] and [] keys to move to the field then [] and [] to
change. Press [OK] to save or [MENU] to exit without saving.
Scroll through hours to change from am to pm.
System > Schedules >
Day
MENU 7-5-2
Sun Mon Tue Wed Thu Fri Sat Hol
Y Y Y Y Y Y Y N
Enter 1 – 8 To Toggle Days ON/OFF, Then Press [OK] To Save
System > Schedules >
Function
MENU 7-5-3
0 = Disabled
0
1 = Area On/Off 3= Operate Output
2 = Area Part On/Off 4 = Timer Group
Use Keys [] and [] keys or enter 0 - 4 + [OK] To Program The
Function the Schedule Will Follow
System > Schedules >
Index
MENU 7-5-4
0
(Enter Digits 0 – 15 To Program Area, Output or Access Group Number,
Then Press [OK] To Save
System > Holidays >
Name
MENU 7-6-0
H o l i d a y N a m e
Use [] and [] Keys To Scroll Cursor Left and Right. Use Keys [0]
– [9] + [#] and [*] To Toggle Characters + Enter [OK] To Save
System > Holidays >
Start Stop Dates
MENU 7-6-1
Start 12am Stop 12am
01 Jan 01 Jan
DD MM DD MM
Use the [] and [] keys to move to the field then [] and [] to
change. Press [OK] to save or [MENU] to exit without saving.
