CONNECT BOSE PRODUCTS
31
|
ENG
Connect a Bose bass module using an audio cable
You can connect the bass module to the soundbar using a 3.5 mm audio cable
(not provided).
If you don’t have a 3.5 mm audio cable (commonly used for headphones and mobile
devices), visit support.bose.com/UltraSBCsupport.bose.com/UltraSBC to purchase a 15 ft (4.5 m) cable. You can
also purchase this part at your local electronics store.
1. Connect one end of a 3.5 mm audio cable to the x connector on the
bass module.
2. Connect the other end of the cable to the h connector on the back of
the soundbar.
Bose Bass Module 500 Bose Bass Module 700
3. Check for sound (see page 50).
