32
Figure 5. AmPlus 100 Simple Mono Installation
Example Listening Zone
Rear Panel Hookup
AmPlus 100 Signal Flow
Source
AmPlus™ 100
Remote
Volume
Control
Remote
Volume
Control
Internal Switch Settings
Remote Volume: 1 Remote,
Ch. 1 High Pass Filter: OFF,
2 Ch./Mixer Switch: 2 Ch.

Note: Both bass pots are active
in this mode. Use both of these
controls to make bass level
adjustments.
BASS
LEVEL
Ch2Ch1
OFF
+10
OFF +10
ZONE 1 ZONE 2
REMOTE
VOLUME
ZONE 1 ZONE 2
LINE OUTPUT
+-+-
INPUT
MODE
2Ch
dual
mono
mono
Ch1
Ch2
INPUTS A
+- +- +-+-+-
70/100V ZONE 1
4-16
ZONE 2
4-16
XFR
CT
MODE
POWER AMPLIFIER
70/100V 2 Ch.
BRIDGED
LEVEL
Zone 2Ch2Ch1
0
-40 dB
-10
Source
L
R
Tap settings
less than or
equal to 100W
-6
0
-40 dB
-10
-6
0
-40 dB
-10
-6
High Pass
Filter
Dynamic
EQ
Bass Boost
Dynamic
EQ
Bass Boost
Bass
Level
Ch. 1
Bass
Level
Ch. 2
+ -
70/100V
Option Card 1
Channel 1
Option Card 1
Channel 2
Ch. 1
Level
Ch. 2
Level
Channel 1
Input
Channel 2
Input
Mono
Dual
Mono
2 Ch.
Input Mode Switch
section 1 of 2
High
Pass
Filter
Switch
Power Amp 1
Power Amp 2
70/100V Bridged
2 Ch.
70/100V Bridged
2 Ch.
XFR
CT
+ -
ZONE 2
+ -
ZONE 1
Zone 1
Remote
Zone 2
Remote
VCA
Control 1
VCA
Control 2
1 Remote
2 Remotes
Line Outputs
ZONE 1
ZONE 2
VCA 1
VCA 2
Mono
2 Ch.
Dual
Mono
Zone 2
Level
EQ Card 1
EQ Card 2
Option Card 2
Channel 1
Option Card 2
Channel 2
Input Mode Switch
section 2 of 2
Remote Switch
Amplifier
Mode
Switch
Power
Amplifier
Outputs
2 Ch.
Mix
2 Ch/
Mixer
Switch
