AMPLUS™ 50 AND 100 ACCESSORY NOTES
1. The AmPlus 50 and 100 Business Music Amplifiers MUST be used with the Power Amplifier
Accessory Kits referred to in Figure 12. These kits supply the necessary parts to allow the
amplifiers to be used in different countries. They include the literature kit, power cord, and
remote volume control required for that voltage and configuration. The amplifiers themselves
are also configured internally for use at 120 or 240 Volts.
2. The AmPlus 50 and 100 Amplifiers can be rack mounted using the optional rack-mount kit.
Refer to Figure 16 for more information.
3. The AmPlus 100 Amplifier can use the optional Opti-Source™ and Opti-Voice
®
Page Option
Cards to extend the abilities of the amplifier in different installations. These Option Cards will
be covered more extensively in the supplement to this service manual (part number
194101-S1).
4. The AmPlus 100 Amplifier can be used with the optional CVT-100 Transformer Accessory
Kit to allow 70/100V operation in both channels. Refer to Figure 15 for more information.
5. The AmPlus 50 and 100 Amplifiers can be used with optional Equalizer Cards to allow the
use of the Free Space
®
Model 1B Acoustimass
®
Module, and the Model 8, Model 25, and
Model 32 Loudspeakers.
Table 14. AmPlus 50 and 100 Amplifiers and Accessories
Item Description Product Code Part Number
Power Amplifiers
AmPlus 100
120Vac
240Vac
Amplus 50
120Vac
240Vac
017803
017804
017805
017806
187915-001
187915-002
187921-001
187921-002
Power Amplifier Accessory Kits
US/Canada
Europe
Japan
U.K.
Australia
017989
017990
017991
017992
017993
187492-001
187492-002
187492-003
187492-004
187492-005
Rack Mount kit 019596 191909-001
Opti-Voice page option card 019073 187515-001
Opti-Source option card 019074 187505-001
CVT-100 Transformer accy kit 020743 193541-001
Model 1B EQ card 019509 190670-001
Model 8 EQ card 015134 184824-001
Model 32 (and Model 25) EQ card 011687 183744-001
