MAIN PART LIST
AmPlus™ 100 Amplifier (see Figure 10)
Item
Number
Description Part Number Qty. Notes
1 SCREW, 6-32 X .5, MACH, FLAT, XREC 190623-008 5
2 COVER TOP, AMP 187966 1
3 TRANSFORMER, AUDIO, 70/100V 188600-001 1
4 CLIP, HEATSINK, BRIDGE RECT. 188568 1
5 NUT, 8-32 HEX W/LKWSHR 100413-2 7
6 CLIP, HEATSINK 188599 2
7 TRANSFORMER, POWER 187985 1
3
8 PCB ASSY, AMPLUS 100,
120V
240V
187917-001
187917-002
1
1
1, 2
1, 2
9 SCR, MACH, 8-32X 1/4, XREC, DRILK 179096-04 6
10 CLIP, HEATSINK 188598 6
11 INSUL. THERMAL COND, TO-220 188642-001 4
12 SCREW, MACH, #10-32, PAN, XREC 177637-44 4
13 INSUL. THERMAL COND., MULTIWATT 188642-002 2
14 HEATSINK, AMPLUS 50/100 187969 2
15 CONN ASSY, IEC RECEPT, AMPLUS 190621-001 1
3
16 CHASSIS, BASE, AMPLUS 100
120V
240V
187963-001
187963-002
1
1
17 SWITCH ASSY, DPST, NEON,
120V
240V
190622-001
190622-002
1
1 3
18 HARNESS ASSY, OPTION, 8 COND 188570 2
- HARNESS ASSY, 12 CONDUCTOR,
MAIN PCB TO AMP MODULE
188571-001 2
