42
ELECTRICAL PART LIST
Resistors
Reference Designator Description Part Number Notes
R1, 2, 3, 4, 5 POT, RTY, 20K, RIGHT
ANGLE, LOG TAPER
187484-001 4
R100, 102, 110, 116, 193, 194, 312,
342, 412, 502, 503, 506, 507, 512,
514, 517, 520, 521, 524, 537, 538,
547, 549, 561, 563, 607, 711, 713
1.00KΩ, 0805, 1/10W, 1% 133625-1001 4
R101, 103, 111, 117, 606 9.09KΩ, 0805, 1/10W, 1% 133625-9091
R104, 105, 112, 118, 121, 171, 180,
181, 200, 201, 213, 214, 217, 219,
220, 221, 236, 237, 304, 311, 313,
330, 335, 341, 343, 370, 372, 505,
510, 519, 526, 560, 564, 567, 569,
600, 601, 705, 706, 708, 709
10.0KΩ, 0805, 1/10W, 1% 133625-1002 4
R106, 115, 182, 183, 184, 185, 186,
187, 188, 189, 202, 223, 235, 245,
246, 247, 401, 408
100Ω, 0805, 1/10W, 1% 133625-1000 4
R113, 130, 133, 181, 190, 192, 213,
214, 219, 237, 244, 328, 369, 391, 604
JUMPER, CHIP, 0805 133627 AmPlus
50
R120, 170, 171, 210, 211, 212, 215,
216, 218, 300, 331, 357
47.5KΩ, 0805, 1/10W, 1% 33625-4752 4
R126, 131, 132, 141, 142, 152, 153,
164, 302, 303, 317, 318, 333, 334,
347, 348, 500, 501, 509, 515, 516,
525, 536, 546, 608, 700, 701
100KΩ, 0805, 1/10W, 1% 133625-1003 4
R150, 154 1.54KΩ, 0805, 1/10W, 1% 133625-1541
R151, 155, 325, 352, 367, 379 14.0KΩ, 0805, 1/10W, 1% 133625-1402 4
R160, 161 3.01KΩ, 0805, 1/10W, 1% 133625-3011 4
R162, 163, 204, 205, 230, 231, 241,
242, 243, 244, 364, 365, 376, 377,
380, 387, 545, 565, 710
30.1KΩ, 0805, 1/10W, 1% 133625-3012 4
R171 10.0KΩ, 0805, 1/10W, 1% 133625-1002
R181, 213, 219, 237 JUMPER, CHIP, 0805 133627
R203, 222 2.00KΩ, 0805, 1/10W, 1% 133625-2001 4
R206, 207, 232, 233 499Ω, 0805, 1/10W, 1% 133625-4990
R234, 326, 327, 358, 359, 382 6.19KΩ, 0805, 1/10W, 1% 133625-6191 4
R301, 332 2.43KΩ, 0805, 1/10W, 1% 133625-2431 4
R305, 339, 410, 704 1MEGΩ, 0805, 1/10W, 5% 133626-1055 4
R306, 307, 337, 338, 504, 518, 535,
543, 702, 703, 712, 714, 715, 717
20.0KΩ, 0805, 1/10W, 1% 133625-2002 4
R308, 340 5.62KΩ, 0805, 1/10W, 1% 133625-5621 4
R310, 316, 336, 345, 362, 371, 373 4.99KΩ, 0805, 1/10W, 1% 133625-4991 4
R314, 344 8.25KΩ, 0805, 1/10W, 1% 133625-8251 4
R315, 346 301KΩ, 0805, 1/10W, 1% 133625-3013 4
R319, 350 25.5KΩ, 0805, 1/10W, 1% 133625-2552 4
R320, 349, 356, 363, 374, 385 26.7KΩ, 0805, 1/10W, 1% 133625-2672 4
R321, 354 4.64KΩ, 0805, 1/10W, 1% 133625-4641 4
R322, 355, 511, 523, 539, 550 6.81KΩ, 0805, 1/10W, 1% 133625-6811 4
R323, 351 4.22KΩ, 0805, 1/10W, 1% 133625-4221 4
R324, 353 6.49KΩ, 0805, 1/10W, 1% 133625-6491 4
R328, 360, 369, 391, 407, 604 JUMPER, CHIP, 0805 133627 4,
AmPlus
100
To Next Page
