43
ELECTRICAL PART LIST
Resistors (continued)
Capacitors
Reference Designator Description Part Number Notes
R366, 378 40.2KΩ, 0805, 1% 133625-4022 4
R381, 386 4.02KΩ, 0805, 1/10W, 1% 133625-4021 4
R400, 409 301Ω, 0805, 1/10W, 1% 133625-3010 4
R402, 403 402Ω, 0805, 1% 133625-4020 4
R411 3.32KΩ, 0805, 1/10W, 1% 133625-3321 4
R414, 415, 541, 571 10Ω, 2512, 1W, 5% 181895-10R0 4
R508, 522, 540, 548 220Ω, 2512, 1W, 5% 181895-2200 4
R527, 529, 532, 533 2.49KΩ, 0805, 1/10W, 1% 133625-2491 4
R528, 530, 531, 534 49.9KΩ, 0805, 1/10W, 1% 133625-4992 4
R568, 570 5.90KΩ, 0805, 1/10W, 1% 133625-5901 4
R602, 603 .75Ω, 1210, 1/4W, 5% 180956-R75E
3
Reference Designator Description Part Number Notes
C1, 2 1000pF, Y-Cap, Rifa P/N:
PME290MA4100M
170183
3
C100, 103, 111, 116 680pF, 0805, COG, 50V, 5% 133622-681
C104, 105, 107, 112, 114, 117,
160, 163, 180, 255, 315, 332
47pF, 0805, COG, 50V, 5% 133622-470 4
C106, 108, 113, 118, 130, 131,
140, 141, 151, 153, 161, 162, 198,
199, 216, 217, 240, 241, 244, 245,
249, 251, 252, 253, 254, 301, 304,
305, 313, 314, 316, 317, 321, 322,
330, 331, 337, 341, 347, 408, 409,
521, 526, 532, 533, 534, 535, 602,
603, 604, 605, 608, 609, 614, 615,
616, 617, 618, 619, 620, 701, 702,
703, 705, 706
.10uF, 0805, Y5V, 25V, 80% 133624 4
C120, 170, 333, 707 4.7uF, EL, 105, 35V, 20% 137126-4R7 4
C150, 152, 302, 303, 308, 319,
320, 325, 500, 501, 503, 505, 506,
510, 511, 513, 514, 516, 518, 522,
523, 527, 528, 529, 612, 613, 700
10UF, EL, 105, 35v, 20% 149948-100V 4
C201, 202, 230, 231, 400, 402,
403, 407
560pF, 0805, COG, 50V, 5% 133622-561 4
C210, 212, 214, 219, 242, 243,
246, 247, 530, 531, 704
100pF, 0805, COG, 50V, 5% 133622-101 4
C211, 213, 215, 218, 318, 360 1.0uF, EL, 105, 50V, 20% 137126-1R0 4
C197, 248, 250, 504, 508, 509,
512, 515, 517, 519, 525
1000pF, 0805, COG, 50V, 5% 133622-102 4
C307, 324 1800PF, 0805, COG, 50V, 5% 133622-182 4
C309, 329 .068uF, BOX, 85, 63V, 5% 137127-683 4
C310, 312, 327, 328, 339, 342 .15uF, BOX, 85, 50V, 5% 137127-154 4
C311, 326 .1uF, BOX, 85, 50V, 5% 137127-104 4
C334, 335, 340 .22uF, BOX, 85, 50V, 5% 137127-224
To Next Page
