Bose AMPLUS 50

44
ELECTRICAL PART LIST
Capacitors (continued)
Diodes
Transistors
Reference Designator Description Part Number Note
Q201, 221, 300, 304, 400, 402,
600, 601, 701
NPN, SOT, MMBT3904 146819 4
Q301, 302, 305, 306, 700 PNP, SOT, MMBT3906 148596 4
Q401, 403 JFET, TO-92 188634-001 4
Q500, 504, 506, 510 BPLR, N, 60V, 200MA, TO-92 117921 4
Q501, 503, 507, 509 BPLR, P, 60V, 200MA, TO-92 119168 4
Q502, 508 DARL, P, TIP146T 172285 4
Q505, 511 DARL, N, TIP141T 172284 4
Reference Designator Description Part Number Note
B600, B601 RECT, BRIDGE, 100V, 6A 170214 3
D200, 201, 202, 203, 300, 306,
511, 515, 603, 700, 701, 702
SOT, MMBD914LT1 148582 4
D301, 305 SOT-23, BAV70 147249 4
D302, 304, 506, 514, 703 BAV99, SOT23 147239 4
D401, 402, 500, 504, 508, 512 ZENER, 5%, 9.1V, SOT-23 148333 4
D501, 503, 507, 510 1N4531, 5MM 136603 4
D502, 505, 509, 513, 600, 601 RECT, 1.5A, S2A 187479-001 4
Reference Designator Description Part Number Notes
C336, 344, 345, 346 .033uF, BOX, 85, 63V, 5% 137127-333 4
C338, 343 .12uF, BOX, 85, 50V, 5% 137127-124 4
C401, 405, 502, 507, 520, 524 .01uF, 0805, X7R, 50V, 5% 133623-1035 4
C406 .033uF, 0805, X7R, 50V, 10% 133623-333
C606, 607 4700UF, EL, BP, 105, 50V,
20%
187394
C610, 611 4700UF, EL, 105, 50V, 20% 144000-472E
