Page #34 background imageLoading...
Page #34 background image
34
Source
AmPlus™ 100
Model 1B
Module
Remote
Volume
Control
Remote
Volume
Control
3. Internal Switch Settings
Remote Volume: 1 Remote,
Ch. 1 High Pass Filter: ON,
2 Ch./Mixer Switch: 2 Ch.
BASS
LEVEL
Ch2Ch1
OFF +10 OFF +10
ZONE 1 ZONE 2
REMOTE
VOLUME
ZONE 1 ZONE 2
LINE OUTPUT
+-+-
INPUT
MODE
2Ch
dual
mono
mono
Ch1
Ch2
INPUTS A
+- +- +-+-+-
70/100V ZONE 1
4-16
ZONE 2
4-16
XFR
CT
MODE
POWER AMPLIFIER
70/100V 2-CH
BRIDGED
LEVEL
Zone 2Ch2Ch1
0-40 dB
-10
-6
Source
L
R
Model 1B
Module
1. First, adjust high
frequency speaker
level here.
2. Then use Zone 2 and
Ch. 2 Bass pots to adjust
Bass Module level.
Use jumper
Tap settings,
less than or
equal to 50W
0-40 dB
-10
-6
0-40 dB
-10
-6
High Pass
Filter
Dynamic
EQ
Bass Boost
Dynamic
EQ
Bass Boost
Bass
Level
Ch. 1
Bass
Level
Ch. 2
Power Amp 1
Power Amp 2
70/100V Bridged
2 Ch.
70/100V Bridged
2 Ch.
XFR
CT
+ -
ZONE 2
+ -
ZONE 1
+ -
70/100V
Zone 1
Remote
Zone 2
Remote
VCA
Control 1
VCA
Control 2
1 Remote
2 Remotes
Line Outputs
ZONE 1
ZONE 2
VCA 1
VCA 2
Mono
2 Ch.
Dual
Mono
Zone 2
Level
EQ Card 1
EQ Card 2
Option Card 2
Channel 1
Option Card 2
Channel 2
Option Card 1
Channel 1
Option Card 1
Channel 2
2 Ch.
Mix
Ch. 1
Level
Ch. 2
Level
Channel 1
Input
Channel 2
Input
Mono
Dual
Mono
2 Ch.
Input Mode
Switch section
1 of 2
2 Ch/
Mixer
Switch
Input Mode
Switch Section 2 of 2
Remote Switch
Amplifier
Mode
Switch
Power
Amplifier
Outputs
High
Pass
Filter
Switch
AmPlus 100 Signal Flow
Rear Panel Hookup
Example Listening Zone
Figure 7. AmPlus 100 70/ 100 Volt Mode/ Model 1B Acoustimass
®
Bass Module Installation
