Bose AMPLUS 50

36
Example Listening Zone
Figure 9. AmPlus 50 Simple Mono Installation
AmPlus 50 Signal Flow
Rear Panel Hookup
Source
AmPlus™ 50
Remote
Volume
Control
Remote
Volume
Control
BASS
GAIN
OFF +10
REMOTE
VOLUME
Ch1
Ch2
INPUTS A
+- +-
LEVEL
Ch2Ch1
0 0-40 dB -40 dB
-10-10
-6 -6
Source
L
R
+-+-
70/100V 4-16
MODE
POWER AMPLIFIER
70/100V 4-16
Tap settings:
less than or
equal to 50W
Internal Switch Settings:
High Pass Filter: OFF
High Pass
Filter
Dynamic
EQ
Bass Boost
Bass
Gain
Power Amp 1
+ -
70/100V
Remote
VCA
Control
VCA
EQ Card
Ch. 1
Level
Ch. 2
Level
Channel 1
Input
Channel 2
Input
4-16
4-16
70/100V
70/100V
+ -
4-16
High
Pass
Filter
Switch
Power
Amplifier
Outputs
Amplifier
Mode
Switch
