47
DSP PCB ELECTRICAL PART LIST
Inductors
Diodes
Transistors
Reference
Designator
Description Part Number Note
Q200 NPN, 47K BIAS RES, SOT23 258024
Q200 BPLR, NPN, 50V, 100mA, SOT23 146817
Q201 NPN, SOT, MMBT3904 146819
Q204 NPN, SOT, MMBT3904 146819
Q500 BPLR, NPN, 50V, 100mA, SOT23 146817
Reference
Designator
Description Part Number Note
L1 400 OHMS, CHIP, 0805 188587-401
L2 400 OHMS, CHIP, 0805 188587-401
L200 400 OHMS, CHIP, 0805 188587-401
L500 100uH, FIXED, SMT, 20% 251161-101
L501 22uH, SMD, 20% 173273-220
Reference
Designator
Description Part Number Note
D1 BAV99, DIODE, DUAL, SOT-23 147239
D2 BAV99, DIODE, DUAL, SOT-23 147239
D3 BAV99, DIODE, DUAL, SOT-23 147239
D100 BAV99, DIODE, DUAL, SOT-23 147239
D102 BAV99, DIODE, DUAL, SOT-23 147239
D103 BAV99, DIODE, DUAL, SOT-23 147239
D104 BAV99, DIODE, DUAL, SOT-23 147239
D105 BAV99, DIODE, DUAL, SOT-23 147239
D200 BAV70, DIODE, DUAL, SOT-23 147249
D202 BAV99, DIODE, DUAL, SOT-23 147239
D500 SCHOTTKY, 40V, 3A 193847-001
ZR200 1N5232, ZENER, 5.6V, 225 MW 135247-5232
ZR201 1N5232, ZENER, 5.6V, 225 MW 135247-5232
