Bose BUILT-INvisible TA-1 User Manual

46
DSP PCB ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator
Description Part Number Note
C206 33pF, 0805, COG, 50V, 5% 133622-330
C207 1.0uF, 1206, X7R, 25V, 10% 262063-105
C208 1.0uF, 1206, X7R, 25V, 10% 262063-105
C209 1000pF, 0805, COG, 50V, 5% 133622-102
C211 330pF, 0805, COG, 50V, 5% 133622-331
C212 330pF, 0805, COG, 50V, 5% 133622-331
C213 330pF, 0805, COG, 50V, 5% 133622-331
C214 1000pF, 0805, COG, 50V, 5% 133622-102
C215 330pF, 0805, COG, 50V, 5% 133622-331
C216 330pF, 0805, COG, 50V, 5% 133622-331
C217 1000pF, 0805, COG, 50V, 5% 133622-102
C400 .033uF, 0805, X7R, 50V, 10% 133623-333
C402 33pF, 0805, COG, 50V, 5% 133622-330
C403 33pF, 0805, COG, 50V, 5% 133622-330
C404 .033uF, 0805, X7R, 50V, 10% 133623-333
C410 33pF, 0805, COG, 50V, 5% 133622-330
C411 33pF, 0805, COG, 50V, 5% 133622-330
C414 .033uF, 0805, X7R, 50V, 10% 133623-333
C415 .033uF, 0805, X7R, 50V, 10% 133623-333
C416 .033uF, 0805, X7R, 50V, 10% 133623-333
C417 .033uF, 0805, X7R, 50V, 10% 133623-333
C418 .033uF, 0805, X7R, 50V, 10% 133623-333
C419 .033uF, 0805, X7R, 50V, 10% 133623-333
C420 .033uF, 0805, X7R, 50V, 10% 133623-333
C421 .033uF, 0805, X7R, 50V, 10% 133623-333
C422 .033uF, 0805, X7R, 50V, 10% 133623-333
C423 .033uF, 0805, X7R, 50V, 10% 133623-333
C424 .033uF, 0805, X7R, 50V, 10% 133623-333
C425 .033uF, 0805, X7R, 50V, 10% 133623-333
C426 .033uF, 0805, X7R, 50V, 10% 133623-333
C427 .033uF, 0805, X7R, 50V, 10% 133623-333
C428 .033uF, 0805, X7R, 50V, 10% 133623-333
C429 .033uF, 0805, X7R, 50V, 10% 133623-333
C500 470uF, EL, 105C, 16V, 20% 137454-471
C501 1200pF, 0805, X7R, 50V, 10% 133623-122
C503 .22uF, BOX, 85C, 50V, 5% 137127-224
C504 .033uF, 0805, X7R, 50V, 10% 133623-333
C505 470uF, EL, 85C, 25V, 20% 149948-471E
C506 .47uF, 1206, X7R, 25V, 10% 262063-474
C507 3300pF, 0805, X7R, 50V, 10% 133623-332
C508 33pF, 0805, COG, 50V, 5% 133622-330
C509 1200pF, 0805, X7R, 50V, 10% 133623-122
C515 10uF, EL, 85C, 25V, 20% 149947-100E
