Bose BUILT-INvisible TA-1 User Manual

45
DSP PCB ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator
Description Part Number Note
C8 1.0uF, 1206, X7R, 25V, 10% 262063-105
C100 3300pF, 0805, X7R, 50V, 10% 133623-332
C102 330pF, 0805, COG, 50V, 5% 133622-331
C103 100pF, 0805, COG, 50V, 5% 133622-101
C104 10uF, EL, 85C, 25V, 20% 149947-100E
C105 3300pF, 0805, X7R, 50V, 10% 133623-332
C106 .01uF, 0805, X7R, 50V, 10% 133623-103
C107 .01uF, 0805, X7R, 50V, 10% 133623-103
C108 .01uF, 0805, X7R, 50V, 10% 133623-103
C109 3300pF, 0805, X7R, 50V, 10% 133623-332
C110 330pF, 0805, COG, 50V, 5% 133622-331
C111 100pF, 0805, COG, 50V, 5% 133622-101
C112 10uF, EL, 85C, 25V, 20% 149947-100E
C113 3300pF, 0805, X7R, 50V, 10% 133623-332
C114 .22uF, TANT, SMT, 35V, 20% 262073-V224A
C115 .022uF, 0805, X7R, 50V, 10% 133623-223
C116 2.2uF, TANT, 10V, 20%, A SIZE 196981-
A225A2
C117 .01uF, 0805, X7R, 50V, 10% 133623-103
C118 .01uF, 0805, X7R, 50V, 10% 133623-103
C121 1000pF, 0805, COG, 50V, 5% 133622-102
C124 1000pF, 0805, COG, 50V, 5% 133622-102
C127 1000pF, 0805, COG, 50V, 5% 133622-102
C130 1000pF, 0805, COG, 50V, 5% 133622-102
C131 .01uF, 0805, X7R, 50V, 10% 133623-103
C132 .01uF, 0805, X7R, 50V, 10% 133623-103
C135 1000pF, 0805, COG, 50V, 5% 133622-102
C138 1000pF, 0805, COG, 50V, 5% 133622-102
C139 39pF, 0805, COG, 50V, 5% 133622-390
C140 39pF, 0805, COG, 50V, 5% 133622-390
C144 .01uF, 0805, X7R, 50V, 10% 133623-103
C145 .01uF, 0805, X7R, 50V, 10% 133623-103
C146 0.01uF, 805, X7R, 50V, 10% 133623-103
C150 47pF, 0805, COG, 50V, 5% 133622-470
C151 .01uF, 0805, X7R, 50V, 10% 133623-103
C155 100pF, 0805, COG, 50V, 5% 133622-101
C156 100pF, 0805, COG, 50V, 5% 133622-101
C157 100pF, 0805, COG, 50V, 5% 133622-101
C158 100pF, 0805, COG, 50V, 5% 133622-101
C159 100pF, 0805, COG, 50V, 5% 133622-101
C160 1000pF, 0805, COG, 50V, 5% 133622-102
C200 .01uF, 0805, X7R, 50V, 10% 133623-103
C201 .01uF, 0805, X7R, 50V, 10% 133623-103
C203 .01uF, 0805, X7R, 50V, 10% 133623-103
C204 10uF, EL, 85C, 25V, 20% 149947-100E
C205 33pF, 0805, COG, 50V, 5% 133622-330
