44
DSP PCB ELECTRICAL PART LIST
Resistors (continued)
Capacitors
Reference
Designator
Description Part Number Note
R257 300 OHM, 0805, 1/10W, 5% 133626-3015
R260 1.00K, CHIP, 0805, 1/10W, 1% 133625-1001
R261 10.0K, 0805, 1/10W, 5% 133626-1035
R262 1.00K, 0805, 1/10W, 1% 133625-1001
R263 30K, 0805, 1/10W, 5% 133626-3035
R265 2.00K, 0805, 1/10W, 5% 133626-2025
R266 1.00K, 0805, 1/10W, 1% 133625-1001
R268 2.00K, 0805, 1/10W, 5% 133626-2025
R270 2.00K, 0805, 1/10W, 5% 133626-2025
R275 30K, CHIP, 0805, 1/10W, 5% 133626-3035
R280 10.0K, 0805, 1/10W, 5% 133626-1035
R281 20K, 0805, 1/10W, 5% 133626-2035
R282 20K, 0805, 1/10W, 5% 133626-2035
R402 3.9K, ARRAY, SMT, 4 POS, 5% 186433-3924
R404 3.9K, ARRAY, SMT, 4 POS, 5% 186433-3924
R405 3.90K, 0805, 1/10W, 5% 133626-3925
R406 75 OHM, CHIP, 0805, 5% 133626-7505
R407 75 OHM, CHIP, 0805, 5% 133626-7505
R408 75 OHM, CHIP, 0805, 5% 133626-7505
R409 510 OHM, 0805, 1/10W, 5% 133626-5115
R410 3.90K, 0805, 1/10W, 5% 133626-3925
R411 3.0K, 0805, 1/10W, 5% 133626-3025
R412 510 OHM, 0805, 1/10W, 5% 133626-5115
R415 3.90K, 0805, 1/10W, 5% 133626-3925
R416 3.90K, 0805, 1/10W, 5% 133626-3925
R417 3.90K, 0805, 1/10W, 5% 133626-3925
R418 3.90K, 0805, 1/10W, 5% 133626-3925
R419 3.90K, 0805, 1/10W, 5% 133626-3925
R420 3.90K, 0805, 1/10W, 5% 133626-3925
R421 3.9K, ARRAY, SMT, 4 POS, 5% 186433-3924
R435 3.90K, 0805, 1/10W, 5% 133626-3925
R500 48.7K, 0805, 1/10W, 1% 133625-4872
R501 301K, 0805, 1/10W, 1% 133625-3013
R502 49.9K, 0805, 1/10W, 1% 133625-4992
R503 4.99K, 0805, 1/10W, 1% 133625-4991
R510 100 OHM, 0805, 1/10W, 5% 133626-1015
Reference
Designator
Description Part Number Note
C1 .01uF, 0805, X7R, 50V, 10% 133623-103
C2 10uF, EL, 85C, 25V, 20% 149947-100E
C3 0.01uF, 0805, X7R, 50V, 10% 133623-103
C4 330pF, 0805, COG, 50V, 5% 133622-331
C5 1.0uF, 1206, X7R, 25V, 10% 262063-105
C6 1.0uF, 1206, X7R, 25V, 10% 262063-105
C7 47pF, 0805, COG, 50V, 5% 133622-470
To Next Page
