Bose L1 Compact Service Manual

15
Electrical Part List
Resistors
Input/Output PCB Assembly
Reference
Designator
Description Vendor Part Number Note
R100 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R101 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R102 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4
R103 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4
R104 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4
R105 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4
R106 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4
R107 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4
R108 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R109 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R110 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R111 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R112 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P-R 4
R113 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R114 150 OHM, RMG, 1/16W, 1%, 0603 4723-151A+P-R 4
R115 150 OHM, RMG, 1/16W, 1%, 0603 4723-151A+P-R 4
R116 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A+P 4
R117 150 OHM, RMG, 1/16W, 1%, 0603 4723-151A+P 4
R118 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4
R119 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4
R120 100K, RMG, 1/16W, 1%, 0603 4723-104A+P 4
R122 39K, RMG, 1/10W, 1%, 0603 4720-393A+P 4
R123 39K, RMG, 1/10W, 1%, 0603 4720-393A+P 4
R124 12K, RMG, 1/16W, 1%, 0603 4723-123A+P 4
R125 150 OHM, RMG, 1/16W, 1%, 0603 4723-154A+P-R 4
R126 75K, RMG, 1/16W, 1%, 0603 4723-753A+P 4
R127 8.87K, RMG, 1/16W, 1%, 0603/1608 4723-8871+P 4
R128 47K, RMG, 1/16W, 1%, 0603/1608 4723-473A+P 4
R129 60.4K, RMG, 1/16W, 1%, 0603/1608 4723-6042+P 4
R130 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R131 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R132 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R133 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R134 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R135 97.6K, RMG, 1/10W, 1%, 0603 4720-9762+P 4
R136 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R137 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P-R 4
R138 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P-R 4
R139 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R140 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R141 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4
R142 43.2K, RMG, 1/10W, 1%, 0603 4720-4322+P 4
R143 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R144 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R145 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R146 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R147 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4
