5
Part List Notes
1. This part is not normally available from Customer Service. Approval from the Field Service
Manager is required before ordering.
2. The individual parts located on the PCBs are listed in the Electrical Part List.
3. This part is critical for safety purposes. Failure to use a substitute replacement with the
same safety characteristics as the recommended replacement part might create shock, fire
and/or other hazards.
4. This part is referenced for informational purposes only. It is not stocked as a repair part. Refer
to the next higher assembly for a replacement part.
Electrostatic Discharge Sensitive (ESDS)
Device Handling
This unit contains ESDS devices. We recommend the following precautions when repairing,
replacing or transporting ESDS devices:
• Perform work at an electrically grounded work station.
• Wear wrist straps that connect to the station or heel straps that connect to conductive
floor mats.
• Avoid touching the leads or contacts of ESDS devices or PC boards even if properly
grounded. Handle boards by the edges only.
• Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert
unprotected devices into materials such as plastic, polystyrene foam, clear plastic bags,
bubble wrap or plastic trays.
L1 Compact Accessory Pack
Part Number
Number
L1 Microphone Accessory Pack,
Includes all items below
322711-0000 -
Audix OM3 Cardioid Dynamic Vocal Microphone 318884-0000 OM3
20' XLR Microphone Cable 318885-0000 CBL-20
Carton, L1 Microphone Accessory Pack, RSC,
10.50x8.50x5.75"
318886-0000 N/A
Cable, Audio, Dual, RCA 185931-01 N/A
Cable, Input, 3.5mm, 6ft, Black 271994-001 N/A
L1 Compact System Versions
L1 Compact Power Stand, 120V (US) 318882-1100
L1 Compact Power Stand, 220V (China) 318882-2100
L1 Compact Power Stand, 100V (Japan) 318882-3100
L1 Compact Power Stand, 230V (Euro) 318882-4100
L1 Compact Power Stand, 240V (UK) 318882-5100
