Bose L1 Compact Service Manual

29
Electrical Part List
Input/Output PCB Assembly
Miscellaneous
Reference
Designator
Description Vendor Part Number Note
CN300A WAFER, 10 PIN, P2 2102-100S+003 4
CN302A WIRE-CONN, 10P, P2.0, #26, UL2468, L=110,
F/M
7012-7033+0 4
CN308A CONNECTOR, 5 PIN, P2.5 (JST 05JQ-BT) 2101-1371+0 4
J100 XLR, FEMALE CONN, NC3FAV1-0 2113-1337+1 4
J200 JACK, RCA, 2P, UPRIGHT, W/R, SILVER 2113-3131+1 4
J202 JACK, PHONE, 5P, 6.4MM, BLACK, W/SW 2113-3269+0 4
SW200 SWITCH, SLIDE, DPDT, 50V, 0.3A, L=12,
16X6.5X8
5200-4984+0 4
VR100 VR, ROTARY, 10K/10CX2, 20%, V, L=15, D
SHAFT, ALPHA
4751-1849+0 4
VR101 VR, 50KBX1, XV09203, PVBN25F, NOBLE 4750-9655+0 4
VR102 VR, 50KBX1, XV09203, PVBN25F, NOBLE 4750-9655+0 4
VR200 VR, 20KAX2, RD902-40-15F, ALPHA 4751-0750+0 4
3.5mm Line Input PCB Assembly
Miscellaneous
Reference
Designator
Description Vendor Part Number Note
CN308B WAFER, 5P, P2.5, RA, M, S5B-XH-A 2101-3255+0 4
J801 JACK, PHONE, 3.5MM, STEREO, 3P 2113-3335+0 4
Output PCB Assembly
Resistors
Reference
Designator
Description Vendor Part Number Note
R330 330 OHM, RMG, 1/16W, 1%, 0603 4723-331A+P 4
R331 330 OHM, RMG, 1/16W, 1%, 0603 4723-331A+P 4
R454 330 OHM, RMG, 1/16W, 1%, 0603 4723-331A+P 4
R455 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R801 6.8K, RMG, 1/16W, 1%, 0603/1608 4723-682A+P 4
R802 6.8K, RMG, 1/16W, 1%, 0603/1608 4723-682A+P 4

Bose L1 Compact Specifications

General

Product color	Black
Recommended usage	Universal
Multi-Room Streaming (MRS) support	-
Number of drivers	6
Speaker placement	Stand-mountable
Audio output channels	- channels
RMS rated power	- W
AirPlay	No
Microphone in	Yes
Connectivity technology	Wired
Power source type	AC

Weight and Dimensions

Depth	425.45 mm
Width	336.55 mm
Height	1993.9 mm
Weight	13240 g
