Bose L1 Compact Service Manual

30
Electrical Part List
Capacitors
Reference
Designator
Description Vendor Part Number Note
C351 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C361 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C362 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C447 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C449 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C450 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C701 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C702 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C801 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C802 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C803 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C804 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
Reference
Designator
Description Vendor Part Number Note
CN302B WAFER, 10 PIN, P2 2102-100S+003 4
J300 JACK, RCA, 2P, W/R, SILVER 2113-1801+2 4
J301 JACK, SOCKET, NRJ6HF (STEREO) 2113-3085+0 4
Miscellaneous
Output PCB Assembly

Bose L1 Compact Specifications

General

Product color	Black
Recommended usage	Universal
Multi-Room Streaming (MRS) support	-
Number of drivers	6
Speaker placement	Stand-mountable
Audio output channels	- channels
RMS rated power	- W
AirPlay	No
Microphone in	Yes
Connectivity technology	Wired
Power source type	AC

Weight and Dimensions

Depth	425.45 mm
Width	336.55 mm
Height	1993.9 mm
Weight	13240 g
