Bose L1 Compact Service Manual

16
Electrical Part List
Resistors (continued)
Input/Output PCB Assembly
Reference
Designator
Description Vendor Part Number Note
R148 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4
R149 270 OHM, RMG, 1/16W, 1%, 0603 4723-271A+P-R 4
R150 270 OHM, RMG, 1/16W, 1%, 0603 4723-271A+P-R 4
R151 34.8K, RMG, 1/10W, 1%, 0603 4720-3482+P 4
R152 68K, RMG, 1/16W, 1%, 0603 4723-683A+P-R 4
R153 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4
R154 48.7K, RMG, 1/10W, 1%, 0603 4720-4872+P 4
R155 17.8K, RMG, 1/16W, 1%, 0603/1608 4723-1782+P 4
R156 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4
R157 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4
R158 6.81K, RMG, 1/10W, 1%, 0603 4720-6811+P 4
R159 13.7K, RMG, 1/10W, 1%, 0603 4720-1372+P 4
R160 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4
R161 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4
R162 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R163 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4
R164 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4
R165 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R166 22K, RMG, 1/16W, 1%, 0603 4723-223A+P-R 4
R167 8.87K, RMG, 1/16W, 1%, 0603/1608 4723-8872+P 4
R168 12K, RMG, 1/16W, 1%, 0603 4723-123A+P 4
R169 3K, RMG, 1/16W, 1%, 0603 4723-302A+P 4
R170 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4
R172 820 OHM, RMG, 1/16W, 1%, 0603/1608 4723-821A+P 4
R173 820 OHM, RMG, 1/16W, 1%, 0603/1608 4723-821A+P 4
R174 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P-R 4
R175 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4
R177 510 OHM, RMG, 1/4W, 5%, 1206 4725-511J+6 4
R178 510 OHM, RMG, 1/4W, 5%, 1206 4725-511J+6 4
R179 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R180 15.8K, RMG, 1/10W, 1%, 0603 4720-1582+P 4
R181 470K, RMG, 1/16W, 1%, 0603 4723-474A+P 4
R182 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P-R 4
R183 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4
R184 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4
R186 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4
R188 10 OHM, RMG, 1/16W, 1%, 0603 4723-100A+P-R 4
R189 10 OHM, RMG, 1/16W, 1%, 0603 4723-100A+P-R 4
R190 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4
R199 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R200 45.3K, RMG, 1/10W, 1%, 0603 4720-4532+P 4
R201 95.3K, RMG, 1/10W, 1%, 0603 4720-9532+P 4
R202 59K, RMG, 1/10W, 1%, 0603 4720-593A+P 4
R203 12K, RMG, 1/16W, 1%, 0603 4723-123A+P 4
R204 7.87K, RMG, 1/10W, 1%, 0603 4720-7871+P 4
R205 9.76K, RMG, 1/16W, 1%, 0603 4723-9761+P 4
R206 9.76K, RMG, 1/16W, 1%, 0603 4723-9761+P 4
R207 95.3K, RMG, 1/10W, 1%, 0603 4720-9532+P 4
R208 7.87K, RMG, 1/10W, 1%, 0603 4720-7871+P 4
