Electrical Part List

Resistors

Power Amplifier PCB Assembly

Reference

Designator

Description Vendor Part

Number

Note

R1 110K, RMG, 1/4W, 5%, 1206 4725-114J+6 4

R2 10 OHM, RMG, 1/8W, 1%, 1206 4721-100A+6 4

R3 49.9 OHM, RMG, 1/4W, 1%, 1206 4725-49R9+6 4

R4 20 OHM, RMG, 1/4W, 1%, 1206 4725-200A+6 4

R5 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4

R6 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4

R7 820K, RMG, 1/8W, 5%, 1206 4721-824J+6 4

R8 820K, RMG, 1/8W, 5%, 1206 4721-824J+6 4

R9 820K, RMG, 1/8W, 5%, 1206 4721-824J+6 4

R10 820K, RMG, 1/8W, 5%, 1206 4721-824J+6 4

R11 820K, RMG, 1/8W, 5%, 1206 4721-824J+6 4

R12 2M, RMG, 1/4W, 1%, 1206 4725-205A+6 4

R13 1.8M, RMG, 1/8W, 1%, 1206 4721-185A+6 4

R14 820K, RMG, 1/8W, 5%, 1206 4721-824J+6 4

R15 820K, RMG, 1/8W, 5%, 1206 4721-824J+6 4

R16 0 OHM, RMG, 1/16W, 1%, 0603 4723-000A+P 4

R18 6.8 OHM, RMG, 1/16W, 1%, 0603 4723-6R8A+P 4

R19 1K, RMG, 1/10W, 1%, 0805 4720-102A+J 4

R20 0 OHM, RMG, 1/16W, 1%, 0603 4723-000A+P 4

R21 22 OHM, RMG, 1W, 5%, 2512 4728-220J+3 4

R22 22 OHM, RMG, 1W, 5%, 2512 4728-220J+3 4

R23 10 OHM, RMG, 1/4W, 5%, 1206 4725-100J+6 4

R24 10 OHM, RMG, 1/4W, 5%, 1206 4725-100J+6 4

R25 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4

R26 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R27 180 OHM, RMG, 1/16W, 1%, 0603/1608 4723-181A+P 4

R28 100K, RMG, 1/16W, 1%, 0603 4723-104A+P 4

R29 16 OHM, RMG, 1/4W, 1%, 1206 4725-160A+6 4

R30 3.3K, RMG, 1/16W, 1%, 0603/1608 4723-332A+P 4

R31 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4

R32 402K, RMG, 1/16W, 1%, 0603 4723-4023+P 4

R33 10 OHM, RMG, 1/4W, 5%, 1206 4725-100J+6 4

R34 24 OHM, RMG, 1/4W, 1%, 1206 4725-240A+6 4

R35 24 OHM, RMG, 1/4W, 1%, 1206 4725-240A+6 4

R36 49.9 OHM, RMG, 1/4W, 1%, 1206 4725-49R9+6 4

R37 49.9 OHM, RMG, 1/4W, 1%, 1206 4725-49R9+6 4

R38 210K, RMG, 1/16W, 1%, 0603 4723-214A+P 4

R39 16 OHM, RMG, 1/4W, 1%, 1206 4725-160A+6 4

R40 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A+P 4

R41 49.9 OHM, RMG, 1/4W, 1%, 1206 4725-49R9+6 4

R42 49.9 OHM, RMG, 1/4W, 1%, 1206 4725-49R9+6 4

R43 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A+P 4

R44 10 OHM, RMG, 1/4W, 5%, 1206 4725-100J+6 4

R45 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R46 5.6K, RMG, 1/16W, 1%, 0603/1608 4723-562A+P 4

R47 39K, RMG, 1/10W, 1%, 0603 4720-393A+P 4
