Electrical Part List

Resistors (continued)

Power Amplifier PCB Assembly

Reference

Designator

Description Vendor Part

Number

Note

R48 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R49 5.6K, RMG, 1/16W, 1%, 0603/1608 4723-562A+P 4

R50 39K, RMG, 1/16W, 5%, 0603 4723-393J+P-R 4

R51 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4

R52 5.6K, RMG, 1/16W, 1%, 0603/1608 4723-562A+P 4

R53 39K, RMG, 1/10W, 1%, 0603 4720-393A+P 4

R54 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R55 30K, RMG, 1/16W, 1%, 0603/1608 4723-303A+P 4

R56 5.6K, RMG, 1/16W, 1%, 0603/1608 4723-562A+P 4

R57 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R58 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A+P 4

R59 100K, RMG, 1/16W, 1%, 0603 4723-104A+P 4

R60 820K, RMG, 1/8W, 5%, 1206 4721-824J+6 4

R62 20 OHM, RMG, 1/4W, 1%, 1206 4725-200A+6 4

R63 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A+P 4

R66 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4

R100 0 OHM, RMG, 1/4W, 5%, 1206 4725-000J+6 4

R535 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4

R538 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A+P 4

Capacitors

Reference

Designator

Description Vendor Part

Number

Note

C1 470uF, CE, 250V, 20%, RL, 25X40, 105C 157R-477M+5-&^T 4

C2 3300pF, CC, 1000V, 10%, RLT, 10X4, X7R,

125C

150N-332K+K-SG 4

C3 470uF, CE, 250V, 20%, RL, 25X40, 105C 157R-477M+5-&^T 4

C4 47uF, CE, 10V, 20%, RLT, 5X11, 105C 157C-476M+K-IUT 4

C5 4.7uF, CE, 63V, 20%, RLT, 5X11, LOW ESR,

105C

157I-475M+K-IURT

C6 0.1uF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4

C7 2200pF, CC, 1000V, 10%, RLT, 6X3, X7R, 125C 150N-222K+K-KE 4

C8 0.68uF, CM, 100V, 5%, RBT, 7.5X11.5, MKS2,

WIMA

153H-684J+V-NVU 4

C9 0.68uF, CM, 100V, 5%, RBT, 7.5X11.5, MKS2,

WIMA

153H-684J+V-NVU 4

C10 0.1uF, CC, 50V, 5%, 0805, 1.25X2 150F-104J+J-BD 4

C11 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4

C12 1000uF, CE, 35V, 20%, RLT, 12.5X25, 105C,

LOW ESR

157Q-108M+K-

X&TR

C13 220pF, CC, 50V, 5%, 0603 150F-221J+P-AC 4

C14 220pF, CC, 50V, 5%, 0603 150F-221J+P-AC 4

C15 47uF, CE, 100V, 20%, RLT10X16, LOW ESR,

105C

157H-476M+K-

S5RT

C16 470uF, CE, 35V, 20%, RLT, 10X20, 105C, LOW

ESR

157Q-477M+K-

S9RT

C17 470uF, CE, 35V, 20%, RLT, 10X20, 105C, LOW

ESR

157Q-477M+K-

S9RT
