Electrical Part List

Input/Output PCB Assembly

Resistors (continued)

Reference

Designator

Description Vendor Part Number Note

R209 12K, RMG, 1/16W, 1%, 0603 4723-123A+P 4

R210 150 OHM, RMG, 1/16W, 1%, 0603 4723-154A+P-R 4

R211 75K, RMG, 1/16W, 1%, 0603 4723-753A+P 4

R213 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4

R214 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4

R215 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R216 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4

R217 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4

R218 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R219 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4

R220 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4

R222 68K, RMG, 1/16W, 1%, 0603 4723-683A+P-R 4

R223 100K, RMG, 1/16W, 1%, 0603 4723-104A+P 4

R224 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4

R225 1.8M, RMG, 1/16W, 1%, 0603 4723-185A+P 4

R226 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4

R227 1.8M, RMG, 1/16W, 1%, 0603 4723-185A+P 4

R228 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R229 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R230 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4

R231 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4

R232 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4

R234 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P-R 4

R236 3.9K, RMG, 1/16W, 1%, 0603/1608 4723-392A+P 4

R238 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4

R239 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4

R240 3.9K, RMG, 1/16W, 1%, 0603/1608 4723-392A+P 4

R241 3.9K, RMG, 1/16W, 1%, 0603/1608 4723-392A+P 4

R243 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P-R 4

R244 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R245 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R246 1.8M, RMG, 1/16W, 1%, 0603 4723-185A+P 4

R247 59K, RMG, 1/10W, 1%, 0603 4720-593A+P 4

R248 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4

R249 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R250 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4

R251 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4

R254 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4

R255 68K, RMG, 1/16W, 1%, 0603 4723-683A+P-R 4

R257 68K, RMG, 1/16W, 1%, 0603 4723-683A+P-R 4

R258 10 OHM, RMG, 1/16W, 1%, 0603 4723-100A+P-R 4

R260 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R262 100K, RMG, 1/16W, 1%, 0603 4723-104A+P 4

R264 1.8M, RMG, 1/16W, 1%, 0603 4723-185A+P 4

R265 6.8K, RMG, 1/16W, 1%, 0603/1608 4723-682A+P 4

R266 6.8K, RMG, 1/16W, 1%, 0603/1608 4723-682A+P 4

R267 22.6K, RMG, 1/10W, 1%, 0603 4720-2262+P 4

R271 510 OHM, RMG, 1/4W, 5%, 1206 4725-511J+6 4
