Electrical Part List

Input/Output PCB Assembly

Resistors (continued)

Reference

Designator

Description Vendor Part Number Note

R272 510 OHM, RMG, 1/4W, 5%, 1206 4725-511J+6 4

R275 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4

R276 15.8K, RMG, 1/10W, 1%, 0603 4720-1582+P 4

R277 470K, RMG, 1/16W, 1%, 0603 4723-474A+P 4

R278 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P-R 4

R279 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4

R280 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4

R282 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4

R283 68K, RMG, 1/16W, 1%, 0603 4723-683A+P-R 4

R285 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A+P 4

R287 100K, RMG, 1/16W, 1%, 0603 4723-104A+P 4

R288 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4

R289 33K, RMG, 1/16W, 1%, 0603 4723-333A+P-R 4

R290 15.8K, RMG, 1/10W, 1%, 0603 4720-1582+P 4

R300 33K, RMG, 1/16W, 1%, 0603 4723-333A+P-R 4

R301 68K, RMG, 1/16W, 1%, 0603 4723-683A+P-R 4

R302 91K, RMG, 1/10W, 1%, 0603 4720-913A+P 4

R303 68K, RMG, 1/16W, 1%, 0603 4723-683A+P-R 4

R304 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R305 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4

R306 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R307 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R308 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4

R309 33K, RMG, 1/16W, 1%, 0603 4723-333A+P-R 4

R311 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R312 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R313 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4

R314 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R315 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R316 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R317 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R318 13.7K, RMG, 1/10W, 1%, 0603 4720-1372+P 4

R319 13.7K, RMG, 1/10W, 1%, 0603 4720-1372+P 4

R320 200K, RMG, 1/16W, 1%, 0603/1608 4723-204A+P 4

R321 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R322 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R325 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4

R326 330 OHM, RMG, 1/16W, 1%, 0603 4723-331A+P 4

R327 10 OHM, RMG, 1/16W, 1%, 0603 4723-100A+P-R 4

R328 470 OHM, RMG, 1/16W, 1%, 0603 4723-471A+P-R 4

R329 470 OHM, RMG, 1/16W, 1%, 0603 4723-471A+P-R 4

R332 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R333 80.6K, RMG, 1/10W, 1%, 0603 4720-8062+P 4

R334 3K, RMG, 1/16W, 1%, 0603 4723-302A+P 4

R335 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4

R336 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4

R337 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R338 39K, RMG, 1/16W, 1%, 0603/1608 4723-393A+P 4

R339 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4
