Electrical Part List

Input/Output PCB Assembly

Resistors (continued)

Reference

Designator

Description Vendor Part Number Note

R340 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R341 158K, RMG, 1/10W, 1%, 0603 4720-1583+P 4

R342 23.2K, RMG, 1/16W, 1%, 0603/1608 4723-2322+P 4

R343 24.3K, RMG, 1/10W, 1%, 0603 4720-2432+P 4

R344 24.3K, RMG, 1/10W, 1%, 0603 4720-2432+P 4

R345 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R346 10K, RMG, 1/16W, 1%, 0603 4723-103A+P-R 4

R347 14K, RMG, 1/16W, 1%, 0603/1608 4723-143A+P 4

R348 7.15K, RMG, 1/16W, 1%, 0603/1608 4723-7151+P 4

R349 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4

R351 80.6K, RMG, 1/10W, 1%, 0603 4720-8062+P 4

R352 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R353 100K, RMG, 1/16W, 1%, 0603 4723-104A+P 4

R354 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4

R356 5.36K, RMG, 1/10W, 1%, 0603 4720-5361+P 4

R357 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4

R358 1.96K, RMG, 1/10W, 1%, 0603 4720-1961+P 4

R359 14K, RMG, 1/16W, 1%, 0603 4723-143A+P 4

R366 107K, RMG, 1/10W, 1%, 0603 4720-1073+P 4

R367 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4

R368 53.6K, RMG, 1/10W, 1%, 0603 4720-5362+P 4

R369 100K, RMG, 1/16W, 1%, 0603 4723-104A+P-R 4

R373 8.45K, RMG, 1/10W, 1%, 0603 4720-8451+P 4

R376 23.2K, RMG, 1/16W, 1%, 0603/1608 4723-2322+P 4

R378 107K, RMG, 1/10W, 1%, 0603 4720-1073+P 4

R381 97.6K, RMG, 1/10W, 1%, 0603 4720-9762+P 4

R386 470K, RMG, 1/16W, 1%, 0603 4723-474A+P 4

R391 470K, RMG, 1/16W, 1%, 0603 4723-474A+P 4

R392 47K, RMG, 1/16W, 1%, 0603 4723-473A+P-R 4

R393 24K, RMG, 1/16W, 1%, 0603 4723-243A+P 4

R394 33K, RMG, 1/16W, 1%, 0603 4723-333A+P-R 4

R395 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4

R396 33K, RMG, 1/16W, 1%, 0603 4723-333A+P-R 4

R397 47K, RMG, 1/16W, 1%, 0603 4723-473A+P-R 4

R399 0 OHM, RMG, 1/16W, 5%, 0603 4723-000J+P 4

R400 33K, RMG, 1/16W, 1%, 0603 4723-333A+P-R 4

R401 47 OHM, RMG, 1/2W, 1%, 2010 4727-470A+W 4

R402 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R403 4.7M, RMG, 1/10W, 1%, 0603 4720-475A+P 4

R404 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R405 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4

R406 47 OHM, RMG, 1/2W, 1%, 2010 4727-470A+W 4

R407 68K, RMG, 1/16W, 1%, 0603 4723-683A+P-R 4

R408 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R409 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R410 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R411 100 OHM, RMG, 1/16W, 1%, 0603 4723-101A+P 4

R412 158K, RMG, 1/10W, 1%, 0603 4720-1583+P 4
