Electrical Part List

Input/Output PCB Assembly

Capacitors

Reference

Designator

Description Vendor Part Number Note

C100 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C101 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4

C102 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4

C103 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4

C105 22uF, CE, 16V, 20%, RLT, 4X7, RC2 157D-226M+K-GME 4

C106 22uF, CE, 16V, 20%, RLT, 4X7, RC2 157D-226M+K-GME 4

C107 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4

C108 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4

C109 10uF, CE, 16V, 20%, RLT, 4X7, ELNA 157D-106M+K-GME 4

C110 0.047uF, CC, 50V, 5%, 0603, 0.8X1.6 150F-473J+P-AC 4

C111 0.047uF, CC, 50V, 5%, 0603, 0.8X1.6 150F-473J+P-AC 4

C112 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4

C113 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4

C114 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4

C115 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C116 220uF, CE, 6.3V, 20%, RLT, 5X11 157B-227M+K-IUI 4

C117 220uF, CE, 6.3V, 20%, RLT, 5X11 157B-227M+K-IUI 4

C118 220uF, CE, 6.3V, 20%, RLT, 5X11 157B-227M+K-IUI 4

C119 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C120 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C121 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C122 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C123 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C124 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C125 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C126 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C127 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C128 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C129 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C130 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C131 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C132 220uF, CE, 6.3V, 20%, RLT, 5X11 157B-227M+K-IUI 4

C133 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C134 100pF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4

C135 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C136 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C137 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C138 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C139 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C140 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C141 0.1uF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

C142 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4

C143 470pF, CC, 50V, 5%, 0603 150F-471J+P-AC 4

C144 470pF, CC, 50V, 5%, 0603 150F-471J+P-AC 4

C145 0.01uF, CC, 50V, 5%, 0603 150F-103J+P-AC 4

C146 10uF, CE, 16V, 20%, RLT, 4X7, ELNA 157D-106M+K-GME 4

C147 1200pF, CC, 50V, 5%, 0603, 0.8X1.6 150F-122J+P-AC 4
