Disassembly Procedures
3.2 Remove the two screws that secure the teflon strip to the front of the end cap # 4 assembly.
Lift off the teflon strip. Remove the four screws that secure the end cap # 4 assembly to the
line array enclosure. Slide off the end cap. Do not unplug the molex connector from the
speaker harness. When re-installing the end cap # 4 assembly, be sure that the green/yellow
ground wire is routed through the notch in the steel bottom plate.
3.3 Grasp the edge of the grille and gently lift it away from the enclosure.
4. Driver Removal
4.1 Perform procedure 1.
4.2 Remove the four screws (24) that secure the driver (23) to the baffle (5).
4.3 Lift the driver out of the baffle. Unplug the wires from the driver terminals. Be sure to
observe polarity when installing the new driver.
5. Upper Line Arry Top End Cap (# 1) Removal
5.1 Remove the fours screws (1&2) that secure the end cap to the line array enclosure.
Lift off the end cap.
6. Upper Line Array Bottom End Cap (# 2) Removal
6.1 Remove the fours screws (1&2) that secure the end cap to the line array enclosure.
Lift off the end cap. Unplug the molex connector from the speaker harness.
7. Lower Line Array Top End Cap (# 3) Removal
7.1 Remove the fours screws (1&2) that secure the end cap to the line array enclosure.
Lift off the end cap. Unplug the molex connector from the speaker harness.
8. Lower Line Array Bottom End Cap (# 4) Removal
8.1 Remove the two screws that secure the teflon strip to the front of the end cap # 4 assembly.
Lift off the teflon strip. Remove the four screws that secure the end cap # 4 assembly to the
line array enclosure. Slide off the end cap. Unplug the molex connector from the speaker
harness.
When re-installing the end cap # 4 assembly, be sure that the green/yellow ground wire is
routed through the notch in the steel bottom plate.
