Settings for the Entire RC-5 (SETUP)
MIDI
Parameter Value (Bold: default) Explanation
RX CTL CH
1–16
Species the receive channel for messages (control changes) that switch memories or
control the RC-5.
OMNI
Species MIDI omni mode.
OFF Messages will be received only on the channel specied by the RX CTL CH setting.
ON Messages are received via all MIDI channels, regardless of the RX CTL CH settings.
RX NOTE CH
1–10–16 Species the receive channel for note messages that play the RC-5’s drum sounds.
TX CH
1–16, RX CTL
Species the MIDI transmit channel.
If this is “RX CTL,” the channel will be the same as the RX CTL CH.
SYNC CLOCK
Species the input to which the tempo clock is synchronized.
AUTO
The RC-5 will normally operate using its internal tempo, but will synchronize the tempo
to MIDI clock if MIDI clock data is being input via the MIDI IN connector or the USB port.
Choose the “AUTO” setting if using the RC-5 as a slave device.
The priority order is MIDI>USB>internal clock.
INTERNAL
The clock uses the tempo specied by the memory.
Choose the “INTERNAL” setting if you don’t want to synchronize the RC-5 to an external
device.
USB Synchronize to the tempo from the USB port.
MIDI Synchronize to the tempo from the MIDI IN connector.
CLOCK OUT
OFF, ON Species whether MIDI clock is transmitted (ON) or not transmitted (OFF).
SYNC START
Species what starts in synchronization when a MIDI start message is received.
OFF Synchronized start does not occur.
ALL Track + rhythm
RHYTHM Rhythm
PC OUT
OFF, ON
Species whether program change messages are transmitted (ON) or not transmitted
(OFF).
MIDI THRU
USB THRU
Species the connector(s) from which MIDI messages received at the MIDI IN connector or the USB port are output.
OFF MIDI messages are not output.
MIDI OUT Output from the MIDI OUT connector.
USB OUT Output from the USB port.
USB/MIDI Output from the USB port and the MIDI OUT connector.
STORAGE
Parameter Value (Bold: default) Explanation
STORAGE
OFF, CONNECT
Change this from the OFF setting when connecting the RC-5 via USB to your computer.
When a connection with the computer is established, the message “CONNECTING...”
appears.
F.RESET
Parameter Value (Bold: default) Explanation
F.RESET
Species the settings that will be returned to their factory-set state.
MEMORY Memory 01–99
SYSTEM System settings
MEM+SYS Memory 01–99 and system settings

Boss Loop Station RC-5 Specifications

General

Memory Slots	99
MIDI I/O	In/Out
Display	LCD
Sampling Frequency	44.1 kHz
Bit Depth	32-bit
Looping Time	13 hours
Rhythm Patterns	57
Power Supply	AC adaptor or 9V battery
Dimensions	73 x 129 x 56 mm
Weight	450 g
Loop Time	13 hours
Output	2 x 1/4"
