Bowflex Max Trainer M7 - Step 5: Attach Rear Shroud and Caps

Assembly / Owner’s Manual
13
5. Attach Rear Shroud and Caps to the Frame Assembly
NOTICE: Place the inside hook of the Rear Shroud on the Frame Assembly and then pivot it up into place.
12
12
2
#2
X1
F
