Bowflex Max Trainer M7 - Hardware and Tools; Hardware List; Tools Required

Assembly / Owner’s Manual
8
Tools
Included Not Included
#2
4 mm
5 mm
6mm
8 mm
(recommended)
13 mm
Item Qty Description Item Qty Description
A 6 SocketHeadHexScrew,M8x1.25x20Black J 4 Lock Nut, M8
B 6 LockWasher,M8x14.8Black K 8 Washer,FlatM8x18
C 4 Washer,FlatM8x18Black L 8 FlatSocketHeadHexScrew,M6x1.0x30Black
D 4 SocketHeadHexScrew,M10x1.5x25Black M 4 SocketHeadHexScrew,M6x1.0x20Black
E 4 Washer,FlatM10x23Black N 4 LockWasher,M6x14.8Black
F 1 PanPhillipsScrew,M5x0.8x20 O 4 Washer,FlatM6x13Black
G 2 Washer,FlatM8x24Black P 6 SocketHeadHexScrew,M6x1.0x20
H 2 Cap Q 6 LockWasher,M6x14.8
I 4 SocketHeadHexScrew,M8x1.0x55
Hardware / Tools
A B C D E F
G H
I J K L M N O P Q
