Bowflex Max Trainer M7 - Parts

Assembly / Owner’s Manual
7
Adecalhasbeenappliedtoallright(“R”)andleft(“L”)partstoassistwithassembly.
Item Qty Description Item Qty Description
6 1 ConsoleAssembly(w/Aerobars) 13 1 Heart Rate Chest Strap
7 2 Pedal 14 1 Stabilizer Shroud, Left
8 1 Rail Assembly 15 1 Stabilizer Shroud, Right
9 2 Leg 16 1 Manual Kit
10 4 Leveler 17 1 Dynamic Handlebar, Left
11 1 Stabilizer Assembly 18 1 Dynamic Handlebar, Right
12 2 Cap
( 2 Boxes )
Box 1
Item Qty Description
1 1 Frame
2 1 Shroud, Rear
3 2 Foot Pad
4 1 Hardware Card
5 1 AC Adapter
Box 2
Parts
