Bowflex MAX Trainer - Hardware and Tools

Assembly / Owner’s Manual
7
Tools
Included Not Included
(recommended)
Hardware / Tools
#2
5mm
6 mm
8 mm
13 mm
A B C D E F
G H
I J K L M N
Item Qty Description Item Qty Description
A 8 SocketHeadHexScrew,M6x1.0x8 H 10 SocketHeadHexScrew,M6x1.0x20
B 4 SocketHeadHexScrew,M8x1.25x55 I 4 SocketHeadHexScrew,M10x1.5x25
C 12 Washer,FlatM8x18 J 4 Washer,FlatM10x23
D 6 SocketHeadHexScrew,M8x1.25x20 K 2 Washer,FlatM8x24
E 1 PanPhillipsScrew,M5x0.8x20 L 4 Washer,FlatM6x13
F 2 Cap M 10 Lock Washer, M6
G 4 Lock Nut, M8 N 6 Lock Washer, M8
(recommended)
