Bowflex PR1000 - Attach the Seat Rail to the Base Assembly

Assembly
Step 6: Attach the Seat Rail to the Base Assembly
Parts
• SeatRailAssembly(fromstep5)
• CompletedAssembly(fromstep2)
Hardware
• (1)3/8”x41/4”HexHeadBolt(#12)
• (2)3/8”Washers(#10)
• (1)3/8”Nut(#11)
• (1)ThreadedKnob(#35)
Tools
• (2)AdjustableWrenches(notincluded)
6-1 Insert the Seat Rail Assembly into the Lower Lat Tower Assembly.
6-2 Install and tighten the hardware.
35
10
10
11
12
Assembly Manual
12
