Bowflex PR1000 - Upper Lat Tower

Assembly
Step 7: Upper Lat Tower
Parts
• UpperLatTower
• LatTowerCrossBarwithPulleysandCables
Hardware
• (2)3/8”x3”HexHeadBolt(#4)
• (4)3/8”Washers(#10)
• (2)3/8”Nut(#11)
Tools
• (2)AdjustableWrenches(notincluded)
7-1 Align the Lat Tower Cross Bar bolt holes with the bolt holes in the Upper Lat Tower bracket.
7-2 Install and tighten the hardware.
Note: Donotunwrapthecablesfromthepulleys.
11
10
4
10
Assembly Manual
13
