After about 5 seconds from the last operation, the room
temperature appears.
In MANUAL operating mode, any temperature can be
chosen between 2°C and 35°C. The newly set temper-
ature will be maintained until further adjustments are
made or until a different operating mode is selected.
11 SYSTEM BYPASS
System bypass is useful during cleaning, maintenance
work or when absent, etc. The unit simply functions as a
clock and room thermometer.
11.1- Remove the main unit of the unit.
11.2- Press the button twice (fig. 51).
The selection made is confirmed by the
symbol activated.
The set temperature reading changes to . After
about 5 seconds from the last operation, the room tem-
perature appears.
11.3- Press the button once to return to the heating
programme (fig. 52). Press the button twice to return to
the cooling programme (fig. 53).
11.4- Reinsert the thermostat main unit.
