Brady BMP21 - Creating Patch Panel Labels

Creating Fixed-Length label with Autosize
BMP21 User Guide 9
Creating a Patch Panel* Label
*Use part numbers M21-375-499 or M21-500-499 when performing this procedure.
1. Press Label Type.
2. Select Patch Panel and press Enter .
3. Press
X until screen reads: Spacing = .2”.
Note: Press X to the flashing cursor and enter the desired spacing.
4. Press T to Serial, then X until the screen reads: On.
5. Press
T to # of Ports, then X until the screen reads: 3
- or -
Type: 3
6. Press
T to Rotation, then X until the pictures displays a horizontal
legend .
7. Press Enter .
8. Type: E000.
9. Press Print
.
10. Clear text from the screen: Press + .
