Description of Functions of Operating Panel
COUNT1 / COUNT2
Selects between sheet counter (not pages!) 1 and 2. When this button is in the outer (released) position,
counter 1 is displayed on the left-hand side of the display, and when the button is in (depressed), counter
2 is displayed.
DUMP BUFFER
During normal double sided printing, a volume of text of less than two pages will not be printed. This is
because the Printer is waiting for a full two page print job. By pushing DUMP BUFFER, the text
remaining in the buffer will be printed. See chapter 1.4, "Interfacing to Computer".
PRINT VALUES
Prints the current values of the LAYOUT, I/O and ASCII-TABLES.
See chapter 2.3, "Print Values".
SCROLL
Scrolls through the menus activated by:
I/O, ASCII-TABLES, LAYOUT 1, LAYOUT 2, LAYOUT 3 or LAYOUT 4 buttons.
RESET COUNT
Resets the sheet counter selected by COUNT1/COUNT2.
TEST PRINT
This button has two functions: Test Print and Ready/Continue.
Test Print:
1st push down:
Prints a X-pattern on both sides of the sheet which shows each pin from each magnet rack printing
on a separate line. Useful when searching for missing dots.
2nd push down:
Prints full cells and empty lines, together with the ASCII-table on both sides of the sheet. Useful
for testing the printing pressure adjustments, and to see how the paper tolerates tightly grouped
dots.
3rd push down:
Prints full cells and empty lines, together with the ASCII-table single-sided. Useful for testing the
printing pressure adjustments.
4th push down:
Prints a test pattern made of dot 1,3,5 and 2,4,6, single-sided. Useful when searching for extra
dots.
5th push down:
As 1st push down etc.
Ready/Continue:
When the Printer runs out of paper, the message PAPER OUT is shown on the display. Insert new
paper, and push TEST PRINT in and out, and the printer will continue printing the last print job.
Do not use RESET PRINTER as this will clear the print job from the Printer's memory!
