Wiring diagram for the enclosed serial cable
Standard RS 232 C cable, 25-25 pin:
25 pin female 25 pin female
1 FG FG 1
2 TD RD 3
3 RD TD 2
4 RTS CTS, DSR 5,6
5,6 CTS, DSR RTS 4
7 SG SG 7
8 DCD DTR 20
20 DTR DCD 8
Wiring diagram for the serial cable with 9 pins adaptor:
Standard RS 232 C cable, 9-25 pin:
9 pin female 25 pin female
1 DCD DTR 20
2 RD TD 2
3 TD RD 3
4 DTR DCD 8
5 SG SG 7
6,8 CTS, DSR RTS 4
7 RTS CTS, DSR 5,6
