Brainchild BTC-2500 - Programming Port and DIP Switch

Front
Panel
Rear
Terminal
1 3 Programming Port and DIP Switch1 3 Programming Port and DIP Switch
Figure 1.3 Access Hole
Overview
Figure 1.3 Access Hole
Overview
Table 1.1 DIP Switch
Configuration
Table 1.1 DIP Switch
Configuration
UM25001G
TC, RTD, mV
0-1V, 0-5V, 1-5V, 0-10V
0-20 mA, 4-20 mA
Input 1
Select
Input 1
Select
All parameters are Unlocked
Only SP1, SEL1 SEL5 are unlocked
Only SP1 is unlocked
All Parameters are locked
Lockout
12
34
DIP SwitchDIP Switch
:ON :OFF
Factory Default SettingFactory Default Setting
8
Access Hole
*
*
The programming port is used for off-line automatic setup and testing procedures only.
Don't attempt to make any connection to these pins when the unit is used for a normal
control purpose.
The programming port is used for off-line automatic setup and testing procedures only.
Don't
attempt to make any connection to these pins when the unit is used for a normal
control
purpose.
When the unit leaves the factory, the DIP switch is set so that TC & RTD are selected for input
1 and all parameters are unlocked.
When the unit leaves the factory, the DIP switch is set so that TC & RTD are selected for input
1 and all parameters are unlocked.
Lockout function is used to disable the adjustment of parameters as well as operation of
calibration mode. However, the menu can still be viewed even under lockout condition.
Lockout function is used to disable the adjustment of parameters as well as operation of
calibration
mode. However, the menu can still be viewed even under lockout condition.
SEL1- SEL5 represent those parameters which are selected by using SEL1, SEL2,...SEL5
parameters contained in Setup menu. Parameters been selected are then allocated at the
beginning of the user menu.
SEL1- SEL5 represent those parameters which are selected by using SEL1, SEL2,...SEL5
parameters contained in Setup menu. Parameters been selected are then allocated at the
beginning of the user menu.
1
ON DIP
234
The programming port is used to connect to
SNA12A for automatic programming, also can be
connected to ATE system for automatic testing &
calibration.
