Glossary V9.xx
48 100-214-273 Rev. 1
Missing Part
A user output signal that indicates trigger occurred above the minimum or below the maximum user-set
allowable distance settings.
Modified Alarm
A user output signal that indicates a user-set compensating condition occurred, (Only energy at this time).
Multi head
Multi head uses more than 1 horn, each horn has its own respective ultrasonic power supply.
No Cycle Alarm
A user output signal that indicates the last weld cycle was aborted due to an abnormal welder internal system
malfunction, an aborted external start signal, or an external cycle abort command.
Note
An alarm condition of the lowest priority.
Overload Alarm
A user output signal that will indicate that a power supply overload condition occurred during the last weld,
test or seek cycle.
Single head
Single head has only 1 horn and power supply.
Sonics Disable
When this User I/O input is active, ultrasonic energy is forced off. If active throughout a weld cycle, a “dry”
cycle will occur: should the weld mode be indeterminate (energy, power, etc) then the time normally used
for the “weld” will extend out to the maximum allowed.
Standard weld cycle
A cycle where the automation controls when the ultrasonic welder is given the start signal, but the welder
controls the entire weld cycle function to the finish,. It then reports to the automation controls it is ready (to
start again) the next weld.
