Aesculap
®
Bonum large animal battery-operated clipping machine
Overview Symbols on product
Ite
m
Art. no. Name
1 GT647801 1 Mounted cutter head housing
2 GT502
GT504
1 Lower cutter plate
3 GT501
GT503
1 Upper cutter plate (for cows)
GT505 1 Upper cutter plate (for horses)
4 GT610010 2 Fixing screw
5 GT367201 1 Oscillator
6 GT367202 2 Guide pin
7 TA008295 6 Oscillating spring leaf
8 GT610307 1 Spring bridge
9 GT367207 2 Fixation screw
10 GT640225 1 Adjusting screw
11 GT610405 1 Knurled nut
12 GT640220 1 Shaft with gear wheel
13 GT610304 1 Oscillating block
14 TA010017 2 Screw, cross-head, M4 x 16
15 TA015497 2 Screw
16 GT367803 1 Right distance part
17 GT367802 1 Left distance part
18 GT367804 1 Mounted oscillator
19 GT146 1 Torqui precision adjusting aid
20 GT640249 1 On/off button (with LED)
21 GT641
(3INR19/66-1)
1 Li-ion battery
22 GT643 (LC40) 1 Charger
a – 1 Lubricating point for battery-operated
clipping machine
b – 1 Tips of the oscillator
c – 1 Hole in the upper cutter plate
d – 1 LED, operation indicator
e – 1 LED, warning indicator
f – 1 Battery lock
g – 1 In the UK
– GT604 1 Special lubricating oil for cutter head and
cutter plates
GT605 1 Gear grease (tube)
Caution, general warning symbol
Caution, see documentation supplied with the product
Labeling of electrical and electronic devices according to
directive 2012/19/EU (WEEE), see Disposal
