7
en
Cleaning the cutter head
► The cutter head must be cleaned at least after each day of clipping time
or if it gets dirty.
► Unlock and remove the lithium ion battery 21.
► Remove both screws 14, see Fig. B.
► Turn the cutter head very slightly (about 15°) counterclockwise and
remove it from the motor shell.
► Remove cutter plates; see Changing cutter plates.
► Thoroughly clean the interior part and individual parts of the cutter
head using a brush.
► Insert the cutter plate and tighten, see Changing cutter plates.
► Grease gear wheel, see Greasing gear wheel.
► Carefully place the cutter head on the motor. When re-attaching the
cutter head, ensure that it is turned 15° counterclockwise in such a
way that its lower flange engages with the groove of the motor hous-
ing.
► Lubricate the shearing head, see Lubricating the shearing head
Re-sharpen the cutter plates
► For sharpening the cutting plate, please contact Technical Service, see
Technical Service.
4.6 Storage
► Clean the clipping machine and cutter plates thoroughly before storing,
see Reprocessing.
► Store the clipping machine in a dry, dark and clean room.
5. Cutter plates
5.1 Cutter plates compatible with cutter head GT647
Cattle version / GT657 Horse version
5.2 Recommended combinations
6. Reprocessing
6.1 Cleaning/disinfection
Art. no. Designation
GT501 Upper cutter plate with 15 cutting teeth
GT502 Lower cutter plate with 31 cutting teeth 3 mm cutting
height
GT503 Upper cutter plate with 17 cutting teeth
GT504 Lower cutter plate with 18 cutting teeth 3 mm cutting
height
GT505 Upper cutter plate with 23 cutting teeth
GT506 Lower cutter plate with 23 cutting teeth 3 mm cutting
height
GT508 Lower cutter plate with 51 cutting teeth 1 mm cutting
height
GT510 Like GT506, but with cutting height of 5 mm
GT511 As GT502, but with cutting height of 1 mm
Combination Upper/lower plate Suitable for
closely spaced
teeth
GT501/GT502 Cattle and horses (normal con-
figuration)
GT501/GT511 Industrial shearing
GT505/GT502 Horses and cattle – smooth
standard shearing
GT505/GT508 Horses, cattle (udder shearing)
and industrial shearing
GT505/GT511 Horses and cattle – for very
fine, smooth shearing
medium spaced
teeth
GT505/GT506 Cattle, dogs and goats
GT505/GT510 Dogs and goats
widely spaced
teeth
GT503/GT504 Cattle, sheep and thin-wooled
sheep
DANGER
Risk of electric shock and fire hazard!
► Before cleaning:
– Remove the mains plug from the
charger.
– Unlock the Li-ion battery and
remove from the battery-oper-
ated clipping machine.
► Do not use flammable or explosive
cleaning or disinfecting solutions.
► Ensure that no fluids will penetrate
the product.
CAUTION
Damage to, or destruction of the prod-
uct caused by mechanical clean-
ing/disinfection!
► Only clean and disinfect the product
manually.
► Do not sterilize the product under
any circumstances.
