28
4.3.10.6 Detection Zone Width
Detection Zone Width sets the overall width of the detection area. This ranges from 2.0m to
16.0m, with the options available being dependent on the “Total Detection Length” selected.
Select the required detection zone width from the drop-down box and click “Apply”.
In a typical application, the detection width would be set to approximately the same width as
the vehicle.
Note: Brigade Backsense
®
automatically adjusts the minimum Detection Width to a higher
value for a longer Detection Length.
Detection Zone Length [m]
Limits for Detection Zone Width [m]
0.6 to 0.8
2 to 16
1
2.5 to 16
1.5 to 3
3 to 16
3.5 to 5.5
3.5 to 16
6 to 8.5
4 to 16
9 to 10.5
4.5 to 16
11 to 13
5 to 16
13.5 to 16
6 to 16
16.5 to 60
7 to 16
