APPENDIX A – SPECIFICATIONS
621A
621B
L A S E R T Y P E
CW and quasi-CW (repetition rate >10 MHz)
W A V E L E N G T H
Range
VIS: 375 - 1100 nm
NIR: 520 - 1700 nm
IR: 1 - 5 µm
VIS: 375 - 1100 nm
NIR: 520 - 1700 nm
IR: 1 - 5 µm
MIR: 2 - 12 µm
Absolute Accuracy
1
± 0.2 ppm
± 0.0002 nm @ 1000 nm
± 0.002 cm
-1
@ 10,000 cm
-1
± 60 MHz @ 300,000 GHz
± 0.75 ppm (± 1 ppm for MIR)
± 0.0008 nm @ 1000 nm
± 0.008 cm
-1
@ 10,000 cm
-1
± 225 MHz @ 300,000 GHz
Repeatability
2, 3
VIS / NIR: ± 0.03 ppm (± 0.03 pm @ 1 µm)
IR: ± 0.06 ppm (± 0.2 pm @ 3 µm)
± 0.1 ppm (± 0.1 pm @ 1000 nm)
Calibration
Continuous - built-in stabilized single-frequency HeNe laser
Continuous - built-in standard HeNe laser
Display Resolution
9 digits
8 digits
Units
4
nm, µm, cm
-1
, GHz, THz
P O W E R ( V I S / N I R )
5
Calibration Accuracy
± 15%
Resolution
2%
Units
mW, µW, dBm
O P T I C A L I N P U T S I G N A L
Maximum Bandwidth
6
1 GHz
10 GHz
Minimum Input
7, 8, 9
VIS: 250 µW (375 nm) 30 µW (750 nm) 125 µW (1100 nm)
NIR: 500 µW (520 nm) 25 µW (1100 nm) 50 µW (1700 nm)
IR: 550 µW (1 µm) 80 µW (3 µm) 750 µW (5 µm)
MIR: 600 µW (2 µm) 150 µW (7 µm) 950 µW (12 µm)
M E A S U R E M E N T R A T E
VIS / NIR: 4 Hz
IR: 2.5 Hz
VIS / NIR: 10 Hz
IR / MIR: 2.5 Hz
I N P U T S / O U T P U T S
Optical Input
10
VIS / NIR: Pre-aligned FC/UPC connector (9/125 µm core diameter) - optional free beam-to-fiber coupler
IR / MIR: Collimated beam, 2-3 mm diameter aperture, visible tracer beam to facilitate alignment
Instrument Interface
High-speed USB 2.0 interface with Windows-based display program
Library of commands for custom and LabVIEW programming
C O M P U T E R R E Q U I R E M E N T S
PC running Windows 7 or 8, at least 1 GB of available RAM,
USB 2.0 (or later) port, monitor, mouse or other pointing device
E N V I R O N M E N T A L
7
Warm-Up Time
< 15 minutes
None
Temperature
+15°C to +30°C (-10°C to +70°C storage)
Pressure
500 - 900 mm Hg
Humidity
≤ 90% R.H. at + 40°C (no condensation)
D I M E N S I O N S A N D W E I G H T
Dimensions (H x W x L)
11
VIS / NIR: 5.6” x 6.5” x 15.0” (142 mm x 165 mm x 381 mm)
IR / MIR: 7.5” x 6.5” x 15.0” (191 mm x 165 mm x 381 mm)
Weight
14 lbs (6.3 kg)
P O W E R R E Q U I R E M E N T S
90 - 264 VAC, 47 - 63 Hz, 50 VA max
(1) Confidence level of 3σ (≥99.6%) and traceable to accepted physical standards.
(2) Standard deviation for a 5 minute measurement period after the instrument has reached thermal equilibrium.
(3) Wavelength resolution is approximately two times repeatability.
(4) Data in units of nm, µm, and cm
-1
are given as vacuum values.
(5) The IR / MIR versions do not measure absolute power. An intensity meter displays relative power.
(6) Bandwidth is FWHM. When bandwidth is greater, wavelength accuracy is reduced.
(7) Characteristic performance, but non-warranted.
(8) For 621B-VIS and 621B-NIR, required input power is about half of values given.
(9) Sensitivity at other wavelengths can be determined from graphs available upon request.
(10) IR and MIR required beam height is 5.4 ± 0.25”
(11) IR and MIR instrument height is adjustable (7.25 ± 0.25”) for alignment purposes.
