6.0 CONFIGURATION AND PARAMETER
SETTINGS
To configure the system and set parameters follow these
steps:
1. Set NT-1 Sensor IDs
2. Set NC-6 Sensor IDs
3. Installer Parameters
4. Set Networker Parameters
6.1 Standard ZonePlus (1x NC-6 and 3x NT-1)
Important Notes:
• All NC-6 Networker Controllers come configured as ‘Master’
devices by default, with the sensor identification pre-set to
“n01”
• There can be only one Master Controller set to “n01” in a
ZonePlus system
• All NT-1 Remote Temperature Sensors come configured as
‘Slave’ devices by default, with sensor identification pre-set
to “n02 ID00:2”
• Zones sensors must be assigned to dampers; see 6.4.4,
p.15
Table 3: Standard 4-Zone System Configuration
Zone ID
Sensor
Type
Sensor
ID
Factory
Setting
Sensor
ID
System
Setting
To modify
Sensor ID
System
Setting
Zone A NC-6 “n01” “n01” n/a
Zone B NT-1 “n02” “n02” n/a
Zone C NT-1 “n02” “n03” Jumper “S3”
Zone D NT-1 “n02” “n04” Jumper “S4”
Always set and record all parameters in the Appendix.
