Brivis ZonePlus B061006 User Manual

21
9.0 Appendix
Table 7: Heater Installer Parameters
Parameter ID
Number and
Default Value
Installer Parameter Description
Installer Parameter
Value Settings NOTE
Please record
the values you
have set
H01 ID01:1250
Maximum Heater fan speed setting,
500 - 1350 RPM Recommend “1350”
H01 ID02:1350
Maximum Cooling fan speed setting,
500 - 1350 RPM Recommend “1350”
H01 ID03:950
Minimum Heating fan speed setting,
500 - 1350 RPM Recommend “500”
H01 ID04:1 Heater “ID” number
1 “1” for single heater system
DO NOT
MODIFY
H01 ID05:500 Circulation fan speed
500 - 1350 RPM Recommend “500”
H01 ID06:45 Heater Supply air temperature (°C)
45 – 70°C Refer Heater Installer Manual
H01 ID07:0 The zoning configuration option
1 ,2, or 5 Refer Table 2, p.6
H01 ID08:1000 Minimum Cooling fan speed
1000 RPM
Do not set below “1000”
(75% of 1350 RPM)
