6.3 Installer Parameters
Accessing
• Press Key “5” on the proposed Slave NC-6 and the screen
will display the message "Clock setting mode". Ensure that
the word “Clock” is flashing on the display before
proceeding
• Press and hold Keys “2” & “4” simultaneously, until the
screen displays the message "Installer parameter
access"
• All setup parameters, once entered, are automatically
saved
Heater Installer Parameters
• Set and record heater installer parameters (“H01 ID01” –
“H01 ID08”) as per Table 7 in the Appendix.
• Press “M” (Mode) to access Master Controller Parameters
(Table 8, p.22)
• Press On/Off to exit
6.4 Setting NC-6 Master Controller Parameters
Important Note:
The Installer Parameter value (“H01 ID07 :#”) must be set in 6.3
(p. 14) to enable specific zoning options before proceeding.
Table 8 (p.22) details all Installer Parameters that may be
made available for setting up the ZonePlus system.
All other parameter values must be set in ascending
sequential order, with the exception of parameter “n01
ID92” (for Multi Temperature Set Point Systems, which
MUST BE SET PRIOR
to setting all other NC-6 parameters).
Set and record all Master Controller Parameters in Table 8
in the Appendix.
6.4.1 Single or Multi Temperature Set Point
The default ZonePlus configuration setting is Single
Temperature Set Point. To activate Multi Temperature Set
Point, parameter “n01 ID92” must be changed from the factory
default setting of “0” to “1”.
When Refrigerated Cooling is installed, the zone
sensor IDs are forced to match those used for Heating. For
example if Heating Zone B sensor ID was set to “n02”, then
Refrigerated Cooling Zone B sensor ID would also be set to
“n02”.
